316LVM curve plate

Product Specification and Size :

1):Standard: ASTM F139.

2):Material designation: Fe-18Cr-14Ni-3Mo

3):Tolerance: h7-h11(on request).

4):Melt method: vacuum melting

5):strip & sheet: 3.2*12mm; 4.2*14mm; 5.2*17.6mm; 6.5*18mm

60s online customer service
2 days customize solutions
Factory visiting anytime
1-10 days dispatch the goods
One week of installation
2 days of training
365 days after-sales online
Project tracking regularly
2 days provide maintenance plan

Pre-sale service

Sales service

After-sales service

Tip1: The specific time arrangement depends on the actual situation. Tip2: Free airport transfer and hotel accommodation.

Product Specification and Size :

1):Standard: ASTM F139.

2):Material designation: Fe-18Cr-14Ni-3Mo

3):Tolerance: h7-h11(on request).

4):Melt method: vacuum melting

5):strip & sheet: 3.2*12mm; 4.2*14mm; 5.2*17.6mm; 6.5*18mm



DESCRIPTION OF 316LVM CURVE PLATE

The characteristics of 316 LVM

L high strength

High fatigue strength

Excellent micro cleanliness

Excellent structural uniformity

High finish

Application:

Temporary and permanent implants

L piercing ornaments

Equivalent grades:

316LVM, ASTM F138, 00Cr18Ni14Mo3, DIN X 2 CrNiMo

Chemical Composition of 316LVM curve plate

Chemical Composition
Grade C Si Mn P S Ni Cr
316 0.08 1.00 2.00 0.045 0.03 10.00-14.00 16.00-18.00
316L 0.03 1.00 2.00 0.045 0.03 10.00-14.00 16.00-18.00
316Ti 0.08 1.00 2.00 0.045 0.03 10.00-14.00 16.00-18.00
316LVM 0.014 0.26 1.63 0.015 0.002 14.71 17.69



 Standard specification:

◇ ISO 5832-1:1997 composition”D”: wrought 18Cr-14Ni-3Mo for surgical implants

◇ GB 4234-2003 composition”S31723″: 18Cr-14Ni-3Mo for surgical implants

◇ ASTM F138: wrought 18Cr-14Ni-2.5Mo bar and wire for surgical implants

◇ ASTM F139: wrought 18Cr-14Ni-2.5Mo sheet and Strip for surgical implants

◇ ASTM F899: wrought stainless steel for surgical instruments



316LS / 316LVM surgical steels are electroslag remelted (ESR) or vacuum arc remelted (VAR), low carbon, high nickel and molybdenum versions of 316 stainless steel. A second high-quality melting step improves cleanliness. Chemical modification is designed to maximize the alloy’s corrosion resistance and provide a ferrite-free microstructure.
